Free digital model of dry stone wall

You can download these dry-stone wall models for free from 3dwarehouse. To find them search for Intresto on 3dwarehouse or follow this link http://sketchup.google.com/3dwarehouse/search?uq=0689629068175189811728180&scoring=m

I made the models by first digitising the shapes of real rocks then I optimised the packing of the virtual rocks using our Rocksolver software application. Rocksolver is the first rock optimisation software application capable of packing rocks together in much the same way a stone mason would.

Intresto's free rock models on 3dwarehouse

Real rock shapes were digitised using a laser scanner then I photographed real rock textures which were applied in Sketchup. There are lots of rock models and they can be downloaded for free from 3dwarehouse. Just search for the Intresto collection on 3dwarehouse or follow this link http://sketchup.google.com/3dwarehouse/search?uq=0689629068175189811728180&scoring=m

You can download the models directly into your Sketchup CAD landscapes. To import into Blender, Maya, 3ds Max or other 3D computer graphics software export from Sketchup as dae, import into MeshLab then export as stl or obj.

Free stone models

I've made some really nice digital 3D stone models using Sketchup and you can download them for free from the Intresto collection on 3dwarehouse here http://sketchup.google.com/3dwarehouse/cldetails?mid=3b6498554492f5bbcaf22741b2e3465e

There are lots of other free rock models and dry-stone wall models in the Intresto collection. If the link above doesn't work go to 3dwarehouse and search for Intresto.

You can download the models directly into Sketchup then export as a dae file and import into MeshLab. From MeshLab the file can be exported in a number of different formats such as obj or stl then used in a whole range of 3D applications like Blender.

Augmented ability software

Augmented ability software uses augmented reality hardware to give someone the ability to do stuff they otherwise wouldn't be able to do.

Imagine wearing augmented reality glasses on a building site where you look at the rocks lying around on the ground, the rock shapes are digitised using the camera in the glasses, Rocksolver optimises rock positions and then shows you where to put each rock. You place the rock in the wall and it fits, like magic.

Rocksolver as Augmented Ability

Recent advances in Augmented Reality (AR) glasses means that it won't be too long before the builders of landscaping, dry-stone walls or stone houses will be able to see the real world and the Rocksolver virtual world through the glasses they are wearing.

Rocksolver software will show the builder which rock to select and where to put it. The view through the glasses will look something like this:

One of the best AR glasses projects is from the Sydney-based company Explore Engage. Check their 2020AR glasses project here.

Wave House 3D model on Google's 3dwarehouse

I've started designing a sustainable house based on a light-weight, insulated outer skin, high thermal mass internal walls made from unprocessed rock and a wave-shaped roof to take advantage of passive solar heating and cooling.

You can download a model of Wave House into your Sketchup world from the Intresto collection on Google's 3dwarehouse. Go to http://sketchup.google.com/3dwarehouse/ and search for "wave house" or "Intresto".

There's more information about the Wave House design on my other blog: http://malbertswavehouse.wordpress.com/

Rocksolver Investor Presentation - 1st November 2011 - Sydney

On Tuesday 1st November 2011 at 5:30pm at the NSW Government’s Trade and Investment Centre on level 47 of the MLC Centre in Sydney the Rocksolver team and I will be presenting Rocksolver as an investment opportunity.

To attend this event please register here http://rocksolver20111101.eventbrite.com/

Malcolm Lambert introduces Rocksolver on ABC TV New Inventors - 6th April 2011

The dry stone wall above features on New Inventors and was built by following a plan automatically generated by the Rocksolver software application. Rocksolver is currently undergoing prototype testing in preparation for its first commercial release later in 2011.

If you'd like to know more about the Rocksolver technology or about Intresto as an investment opportunity please leave your contact details at http://www.intresto.com.au/contact-us

More 3D virtual rocks

The rocks in the image above are all virtual 3d models and are a selection of over 60 models available for download from the Intresto collection on Google’s 3dwarehouse (http://sketchup.google.com/3dwarehouse).

All the models were derived from real rocks so they have a natural look even when scaled to the size of a small stone or large boulder. The models were generated from a 3D laser scanner or from the point cloud derived from the Photosynth photogrammetry application. The models were processed as triangular meshes using MeshLab and then textures applied using Sketchup.

The models can be imported for free directly into Sketchup, used in your landscaping or hardscaping projects or exported as a Collada dae file then imported into Meshlab. From MeshLab they can be saved in a range of 3D formats such as VRML, obj, ply or stl then imported into CAD or 3D animation, graphics and rendering applications such as Blender. Have fun.

My new website - intresto.com.au

It's the same name as the old website but it's been redesigned:

intresto.com.au

Rocksolver builds a wall

Even before structural stability criteria have been explicitly programmed into Rocksolver it has built a stable structure. The photo shows Rocksolver's automatically generated design and the small desk-top structure built from real rocks following Rocksolver's plan. Rocksolver is using a 2D optimisation algorithm which would suit many applications such as retaining walls where stone masons already select prism-shaped rock. Stone masons mostly use a mental 2D algorithm to build a variety of structures from prism-shaped rocks because that's a lot easier than the mental 3D manipulations required to build with a random selection of rocks. Already Rocksolver has the capability to use 3D algorithms and build with random irregular shapes. Results from 3D testing will be published here and at intresto.com.au as they come to hand.

Could be a world first

The image on the left is the result of running a Rocksolver simulation using data corresponding to 5 real rocks. The right-hand image is the real structure built by following the packing plan devised by Rocksolver. This could be the first time a new structure has been built from irregular objects following instructions from a computer program. It's possible some old structures have been re-built following the output from archaeological reconstruction software. The software required to simulate the rebuilding of an old structure is quite different to that required to simulate the building of a new structure so I'm happy to say it's a first.
The packing plan in the image came from my first desk-top simulation, even before the packing algorithm parameters had been optimised so things will only get better from here on.

3D virtual rocks on Google's Sketchup

These 3D virtual rocks come from real rocks which were scanned. The virtual rock mesh was reduced to just a few hundred faces, imported into Sketchup then uploaded to Google's 3dwarehouse where they are freely available for download from the Intresto collection.

Intresto

Intresto Pty Ltd is a company I have just started to help me attract government funding (governments will fund companies but not individuals) so I can keep going with the research and development. Intresto is from Intelligent Rearrangement of Stone, something people have been doing for thousands of years, I'm just throwing a computer into the mix. Have a look at www.intresto.com.au (formerly www.rocksolver.com).

The ant survives

In the high resolution animation it's possible to see the ant scurry over the hills in the distance after it nearly gets squashed by the first rock. I modelled the ant on the Bull Ants living under the front windows of the house I built at Oyster Cove.

My invention

My invention, the "rocksolver" (see www.intresto.com.au), uses a computer to fit together irregular polyhedra, each of which approximates the shape of a rock used to build a wall. When the computer finds a rock to fit into the wall it outputs instructions to the builder as to the rock's position and orientation. The 3D shape of the rocks can be acquired by using a laser scanner or by digital photgraphy.
Have a look at www.intresto.com.au (formerly www.rocksolver.com) for more information.
